3 Channel RGB DMX 512 Module for for 12V DC RGB Lights

Availability: In stock

Regular Price: $17.50

Special Price: $9.50

OR

Quick Overview

The 3-Channel DMX RGB Controller is a 12V 3-Channel module that is small but powerful controller that transforms the DMX-512 standard digital control signals into PWM controller signals for driving LEDs.

3 Channel RGB DMX 512 Module for for 12V DC RGB Lights

Double click on above image to view full picture

Zoom Out
Zoom In

More Views

Details

Supply voltage: 12V DC
Output: 3 channels
Grayscale: 256
The number of occupied channel: 3
Connecting mode: common anode
External dimension: L72ΧW38ΧH26 mm
Static power consumption: <1W
Output current: <4A(each channel)
Output power:12V:<144W

The Controller is built in a weather resistant case allowing it to be used for your outdoor displays and has the ability to achieve different effects such as dimming, ramping, twinkle and shimmer. Each output channels can handle a max of 2A per channel/color. The controller comes pre-programmed to DMX channels 1, 2, 3.

The controller 12V DC Power INPUT, DMX512 signal INPUT and  RGB OUTPUT (1 - 12V positive and 3 - RGB negatives) wires are left open so YOU have many differentoptions for connectivity.
