DMX512 to SPI Universal Signal Decoder with Adjustable IC and Remote Control, 5-24VDC
The DMX512 Pixel Decoder for Multiple IC Chips is a multi-use pixel controller, and is the key component for creating intelligent LED lighting. It is capable of creating pixel scenes from 35 preset modes when controlled by the remote control, or of converting DMX data to SPI protocol for total control of your lights.It can control 512 DMX channels for the following IC types TM1803, TM1804, TM1809, TM1812, TLS3001, TLS3002, LPD6803, LPD1101, LPD8803, LPD8806, D705, UCS1903, UCS1912, UCS2903, UCS2909, UCS2912, UCS6909, UCS6912, WS2811, P9813.
Voltage: 5 to 24 Volts DC
Dimensions: 6.89” x 2.05” x 1.30”(175 mm x 52 mm x 33 mm)
Outputs: V+, CLK, DATA
Operating Temperature: -22 to 150°F (-30 to 65°C)
Features:
1. DC+ Input power to decoder feeds into DC+ input power for connected PixelPro lights.
2. Compatible with standard DMX512 output, enabling individual pixel control.
3. Decode a maximum of 512 DMX addresses (one universe). 170 pixels of PixelPro LED strip light or 170 modules of PixelPro LED bullets, domes, circles, squares, or rectangles.
4. Converts standard DMX output to digital SPI signals suitable for driving any of 23 different IC chips.
5. 35 pre-set modes available that do not require DMX input.
6. Controllable by IR remote.
7. Compatible with the PixelPro line of individually digitally addressable RGB LED strip lights and modules, available in 5 VDC or 12 VDC.
8. Compatible with six types of RGB LED node configurations.
9. Outputs are clock and data signals, defined independently under direction of the DMX
Click here to check the manual of this DMX512 to SPI Universal Signal Decoder
