10W Dual Gooseneck LED DMX Fiber Optic Illuminator with Remote Controller
- Buy 5 for $269.00 each and save 4%
- Buy 10 for $265.00 each and save 5%
- Buy 30 for $259.00 each and save 7%
Voltage: 12V DC
Power: 15W
Color: 6colors
LED: 2-5W LED
LED Life: 50000H
Quantity of fiber:0.75mm 250pcs Single-head
Pls click here to check the datasheet of this dmx LED fiber illuminator
Installation of the fiber optic:
1. Cut the fiber to the specified length;
2. Peel off 5-10cm of the protection cover of the fiber optic (if no protection cover,no need to peel off any fiber optic), be careful not to hurt the fiber optic itself;
3. Insert the fiber optic into light engine connector, screw the waterproof connector tightly. Cut the fiber optic smoothly along with light engine connector with hot knife;
4. Screw the whole light engine connector into the fiber fixing ring.
Installation of fiber optic lights:
Drill on the mounting plate to shape the sign that you need, pass the fiber through the hole, paste the fiber onto the plate with resin glue, then cut the fiber into the requested length(keep the fiber ends 2-3mm away from the mounted board when you are going to
install the star sky).
Notice: 1. please choose the fiber connector with suitable inner diameter according to the
total fiber harness diameter;
2. Please make sure the section of fiber optic clear
